MIL-PRF-55310/34C
2
Ltr
Inches mm
Min Max Min Max
A .345 Typ .355 Typ 8.76 Typ 9.02 Typ
B .285 Typ .295 Typ 7.24 Typ 7.50 Typ
C .086 .114 2.18 2.90
D .195 .205 4.95 5.20
E --- .040 --- 1.02
F --- .320 --- 8.13
G .232 .248 5.89 6.30
H --- .170 --- 4.32
J .015 .021 0.38 0.53
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.005 (0.13 mm) for three place decimals and ±.02 (0.5 mm) for two
place decimals.
FIGURE 1. Interface and physical dimensions - Continued.
Pin number Function
1 Enable/disable
2 GND
3 Output
4 B+
