Q-Tech QT1C User Manual
Page 3

MIL-PRF-55310/12H
3
TABLE I. Dash numbers and operating characteristics.
Frequency-temperature tolerance (one-half temperature cycle, referenced to frequency measured at +23
C
1C, immediately prior to starting of the test): See table I. Measurements taken at ten equally spaced increments
over the specified operating temperature range. 1/
Frequency-voltage tolerance:
1 ppm maximum for a 10 percent change in supply voltage. Measurements taken
at reference temperature and operating temperature range end points.
Frequency aging: Measurements shall be taken at +70
C 0.2C at intervals of not more than every 72 hours for a
minimum of 30 days.
5 ppm per year, maximum
10 ppm per year, maximum
0.7 ppm per 30 days.
1.5 ppm per 30 days
1.5 ppm per 90 days
3 ppm per 90 days
Te
Applied force: 2 pounds each terminal for 10 seconds.
Bends: Five at 45 degrees each.
Frequency-environmental tolerance: Not applicable.
Vibration, sinusoidal: In accordance wi
Nonoperating: Test condition D.
Operating: Not required.
Ambient pressure:
Nonoperating: In accordance wi
, test condition C.
1/ Fo
renamed ‘Frequency-temperature tolerance’. The verification requirements of ‘initial frequency-temperature
accuracy (one-half temperature cycle)’ shall apply except that frequency measurements shall be referenced to
the frequency measured at +23
C 1C (f
ref
) instead of to the nominal frequency (f
nom
).
Dash
num-
ber
Output
frequency
range
Supply
voltage
5%
Input
current
(max)
Output voltage
Rise
and
fall
times
(max)
Duty
cycle
Frequency-temperature
tolerance (ppm)
Logic: 1
(min)
Logic: 0
(max)
-55
C
to
+125
C
-55
C
to
+105
C
-20
C
to
+70
C
A
B
C
MHz V
dc mA V
dc V
dc ns percent
01
.05 through 6
+15
35
13
2
30
40 to 60
100
70
55
02
6 through 10
+15
40
13
2
30
40 to 60
100
70
55
03
.05 through 6
+12
25
10
1
60
40 to 60
100
70
55
04
6 through 10
+12
30
10
1
60
40 to 60
100
70
55
05
.05 through 6
+10
20
9.5
0.5
60
40 to 60
100
70
55
06
6 through 10
+10
20
9.5
0.5
60
40 to 60
100
70
55
