MIL-PRF-55310/12H
2
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Mounting: See figure 1.
Terminals: See figure 1.
Seal: Hermetic in accordance with
MIL-PRF-55310 , maximum leakage rate 5 x 10
-8
atm cc/s.
Weight: 0.175 ounce, maximum.
Oscillator: Class 2 or any class 1 or class 3 oscillator meeting all class 2 requirements and verification tests
specified herein and in MIL-PRF-55310 .
Calibration: Manufacturer calibrated.
Screening: In accordance with MIL-PRF-55310 , product level B or S, as applicable.
Temperature:
Operating: See table I.
Storage: -62
C to +125C.
Oscillator load: 10 kilohms
5 percent shunted by a 15 pF 5 percent capacitor for a CMOS compatible square
wave output.
Output waveform: Symmetrical square wave.
Supply voltage: See table I.
Input current: At designated supply voltage (see table I).
Output frequency: Frequency as designated at time of acquisition (see table I).
Output voltage:
Logic 1: See table I.
Logic 0: See table I.
Rise and fall times: See table I.
Duty cycle: See table I.
Initial accuracy at reference temperature:
25 ppm at +23C 1C up to 30 days after shipment.
Initial frequency-temperature accuracy (one-half temperature cycle): Verification applicable. 1/
