Q-Tech QT806 Sine Wave - Manual (Page 6)

Q-TECH Corporation
10150 W. Jefferson Blvd.
Culver City, CA 90232
SIZE
A
CAGE NO.
51774
QT804, QT805 and QT806
Sine-Wave 24 DDIP REV.
E
Page 6 of 10
Group C Inspection1
Group C Electrical Inspections are performed on a 100% basis
NOTE: Samples from Subgroup 1 may be divided and used for Subgroups 3 and 4
Inspections.
SUB-
GROUP
TEST
DESCRIPTION
CONDITION QTY
1
Vibration
(random)
MI-STD 202 Method 214/ T.C. I-K (46Grms) for 3 minutes
in each plane.
4 parts
(0 failures)
Shock
MI-STD 202 Method 213 T.C. F
(1500g, 0.5ms half-sine pulse) 3 blows each direction of
three axes (18 shocks total)
Electrical Test
Frequency, Output levels, Input Current
@ +25°C & Temp Extremes listed on the Electrical
Specification.
Hermetic Seal
Fine Leak – MIL-STD-883 Method 1014 Condition A1
Gross Leak – MIL-STD-883, Method 1014 Condition C
Electrical Test
Frequency, Output levels, Input Current
@ +25°C & Temp Extremes listed on the Electrical
Specification.
Temperature
Cycling
MI-STD 883, Method 1010, TC B 100 cycles.
Electrical Test
Frequency, Output levels, Input Current
@ +25°C & Temp Extremes listed on the Electrical
Specification
Ambient Pressure
(Non-Operating 2 MI-STD 202 Method 105 T.C. C
Electrical Test
Frequency, Output levels, Input Current
@ +25°C & Temp Extremes listed on the Electrical
Specification
Storage
Temperature
Low Temp.of - 55 (+0, -5) °C
HighTemp.of +150 (+5,-0) °C
Hermetic Seal
Fine Leak – MIL-STD-883 Method 1014 Condition A1
Gross Leak – MIL-STD-883, Method 1014 Condition C
Electrical Test Frequency, Output levels, Input Current @ +25°C & Temp
Extremes listed on the Electrical Specification
3
Resistance to
Soldering Heat MI-STD 202 Method 210 T.C. B
1 parts
(0 failures)
Hermetic Seal
Fine Leak – MIL-STD-883,Method 1014 Condition A1
Gross Leak – MIL-STD-883, Method 1014 Condition C
Moisture
Resistance
MI-STD 202 Method 106
4
Terminal
Strength (Lead
Integrity)
MI-STD 202 Method 211 T.C. B
1 parts
(0 failures)
Visual Inspection
Hermetic Seal
Fine Leak – MIL-STD-883,Method 1014 Condition A1
Gross Leak – MIL-STD-883, Method 1014 Condition C
Resistance To
Solvents
MI-STD 202 Method 215
