Pro Series 51153 51 Receiver - Manual

Installation Instructions
Lexus RX300
Toyota Highlander
Part Numbers:
51153
Hitch Shown In Proper Position
Equipment Required:
Wrenches: 14mm, 17mm
Drill Bits: None
1. Remove tow hooks from frame rails and return to vehicle owner.
2. Remove plastic caps in forward attaching holes.
3. Raise hitch into position and install fasteners as shown above.
Tighten all M10 x 1.25 CL10.9 fasteners with torque wrench to 42 Lb.-Ft. (57 N*M)
Rev. A 8-17-09 51153N Sheet 1 of 3 z 2009 Cequent Performance Products
Conical Toothed Washer 3/8” Qty. (6) 2 Hex Bolt M10 x 1.25x 30mm CL10.9 Qty. (6) 1
Note: check hitch frequently, making sure all fasteners and ball are properly tightened. If hitch is removed, plug all holes in trunk pan or other body panels to prevent
entry of water and exhaust fumes. A hitch or ball which has been damaged should be removed and replaced. Observe safety precautions when working beneath a
vehicle and wear eye protection. Do not cut access or attachment holes with a torch.
This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C. Regulation V-5 and
SAE J684.
Fastener Kit: 51153F
Do Not Exceed Lower of Towing Vehicle
Manufacturer’s Rating or
350 (159 Kg.) 3500 (1589 Kg.)
Weight Carrying
Ball Mount
Do Not Use With Spring Bars Weight Distributing
Max Tongue
WT (LB)
Max Gross
Trailer WT (LB)
Hitch type
Wiring Access Location: SUV1, SUV2
Form: F205 Rev A 5-6-05
Fascia
Frame Rail
Existing Weldnut
Fasteners Typical
Both Sides
