HD132x Series User Manual
24
Figure 4.11 [System Info] Window
Group Symbol Description Remark
MAC Address MAC Address
IP Address IP Address
Base TCP port # Basic TCP port #
Current TCP port # Current TCP port #
Current TCP State Current TCP State
TCP State timer Elapsed time of the TCP State
Power-ON timer Elapsed time after Power-On
IP setup mode IP setup mode
TCP mode setup TCP operation mode setup
Current TCP mode Current TCP operation mode
HelloDevice
Info
Default Router IP address of the Default Router
MAC Address MAC address of Client
IP Address IP address of Client
TCP COM
Client info
TCP port # Port # of Client
HD is Server or
Server/Client mode
MAC Address MAC address of Server
IP Address IP address of Server
TCP COM
Server info
TCP port # Port # of Server
HD is Client or
Server/Client Mode
Table 4.1. Summary of [System Info]
