SENA HD132x Series User Manual
Page 15
HD132x Series User Manual
15
Hub & Switch
Ethernet Cable
7.5V DC Pwer
110/220 V
HD1320E
Ethernet backbone
Figure 4.2. Connection of HD1320E and Ethernet Cable
(3) Check to see if the Tx LED in Status LED's blinks every second. Tx LED blinks periodically when
an IP address is not assigned, which is normal at this stage. (See [Status LED's] in Figure 3.1).
