1: Introduction
Software: Customized lens transmittance and color calculation software
Quality: Conforms with ISO 8980-3, ISO 13666:1998, and CIE standards and
norms
Manufacturing compliance: CE/UL/RoHS/WEEE
Performance
Transmittance measurement
accuracy: +/-1.0%
Transmittance measurement
precision: +/-0.1%
Data acquisition time: typically <5 seconds
Light source output: 20 watts
Light source stability: 0.5% (~15 minutes to stabilize)
Light source drift: <0.3% per hour
Bulb lifetime: 2,000 hours
Bulb color temperature: 3,000 K
Light source temperature: 5 °C - 35 °C
Light source humidity: 5-95% RH
Computer & Power Requirements
Operating systems: Windows Operating System
Computer interfaces: USB 2.0 @ 480 Mbps
Power requirements: 100-240V, 50-60 Hz, 1.5A
EEPROM Utilization
An EEPROM memory chip in each spectrometer contains wavelength calibration coefficients, linearity
coefficients, and a serial number unique to each individual spectrometer. The OOI software application
reads these values directly from the spectrometer, enabling the ability to “hot-swap” spectrometers
between computers without entering the spectrometer coefficients manually on each computer.
Shipment Components
‰
OTS system
OTS-00000-000-02-1008 3
