EMBED2000+ Data Sheet
029-20000-005-05-201305
3
Specifications
Specifications
Criteria
Absolute Maximum Ratings:
V
CC
Voltage on any non-Vcc pin
5 VDC
3.5 VDC
Physical Specifications:
Physical Dimensions
Weight
89.1 mm x 63.3 mm x 34.4 mm
190 g
Power:
Supply voltage
Power requirement
2.63 - 3.3 VDC
100 mA @ 3.3 VDC
Spectrometer:
Design
Focal length (input)
Focal length (output)
Input Fiber Connector
Gratings
Entrance Slit
Detector
Filters
Asymmetric crossed Czerny-Turner
42mm
68mm (75, 83, and 90mm focal lengths are also available)
SMA 905
14 different gratings, plus Grating #31 for the XR version
5, 10, 25, 50, 100,
or 200 μm slits. (Slits are optional. In the
absence of a slit, the fiber acts as the entrance slit.)
Sony ILX511B CCD
2
nd
and 3
rd
order rejection, long pass (optional)
Spectroscopic:
Integration Time
Dynamic Range
Signal-to-Noise
Readout Noise (single dark spectrum)
Resolution (FWHM)
Stray Light
Spectrometer Channels
1 ms – >60 sec
1300:1 (per pixel)
250:1 single acquisition
50 counts RMS, 300 counts peak-to-peak
0.03 – 10.0 nm varies by configuration (see
for configuration options)
<0.05% at 600 nm; <0.10% at 435 nm
One
Environmental Conditions:
Temperature
Humidity
-30
° to +70° C Storage & -10° to +50° C Operation
0% - 90% non-condensing
