1: Introduction
6. The spectrometer passes the sample information to OOI software.
7. OOI software compares the sample to the reference measurement and displays processed spectral
information.
Modular Sampling Accessories
Ocean Optics offers a complete line of spectroscopic accessories for use with the HR4000. Most of our
spectroscopic accessories have SMA connectors for application flexibility. Accordingly, changing the
sampling system components is as easy as unscrewing a connector and replacing an accessory.
Interface Options
The HR4000 has both USB and serial port connectors (with the use of an adapter), enabling you to
connect the spectrometer to a desktop or notebook computer via a USB port or to a desktop, notebook, or
to handheld PC via a serial port. However, you must create custom software if using the serial port.
SpectraSuite software is available if you are connecting via the USB port.
Computer
Interface
Operating System Requirements Part Needed Description of Part
Computer via
USB Port
SpectraSuite: Windows2000/XPfor PC,
OS X version 10.0 or later for Mac, or
Red Hat 9 or later, Fedora (any
version), Debian 3.1 (Sarge), and SUSE
(9.0 or later) for Linux
OOIBase32: Windows 98/Me/ 2000/XP
USB-CBL-1
(included)
Cable that connects from USB
port on HR4000 to USB port on
the computer
Desktop or
Notebook PC
via Serial
Port
Any 32-bit Windows operating system
USB-ADP-PC
(not included)
Adapter block that enables
connection from serial port on
HR4000 to serial port on desktop
or notebook PC; comes with 5
VDC power supply (required
when connecting to serial port)
Handheld PC
via Serial Port
Windows CE 2.11 or higher
USB-ADP-H
(not included)
Adapter block that enables
connection (with standard 9-pin serial
cable) from serial port on HR4000 to
serial port on handheld PC; comes
with 5 VDC power supply (required
when connecting to serial port)
Breakout Box
Ocean Optics also offers the Breakout Box (HR4-BREAKOUT), a passive module that separates the
signals from their 30-pin port to an array of standard connectors and headers, enabling easy access to a
variety of features found in Ocean Optics’ HR4000 Spectrometer. In addition to the accessory connector,
the breakout box features a circuit board based on a neutral breadboard pattern that allows custom
circuitry to be prototyped on the board itself.
