Chapter 2
Setup
Overview
Setting up your LWCC involves unpacking the device and making fiber and plumbing connections.
Unpacking the LWCC
Upon receipt of this instrument, make a thorough inspection of the contents and check for possible
damage. Note any missing cartons or obvious damage to cartons on the delivery receipt before signing.
Report concealed loss or damage at once to the carrier and request an inspection (see
for information on returns). Call Ocean Optics if any parts are missing.
Contents
Your LWCC package should contain the following:
LWCC unit
Luer-fitted PEEK connectors with caps (package of 2)
Quality Control document – Contains the effective optical pathlength of the cell for this LWCC
unit
Other Accessories Not Provided
The following accessories for your LWCC are required, but must be ordered separately:
500 or 600 µm Fiber optic cables (2)
Detection system including either a spectrophotometer, or a spectrometer and a light source
In addition, an optional Waveguide Cleaning Kit (LPC-CLEANKIT) is available from Ocean Optics. This
kit is recommended for cleaning the LWCC between uses and sample runs.
Visit our website
for a complete list of Ocean Optics products.
