19
AFS
™
224
AFS™ 224 User Manual
Technical Information
Specifications
Analog Inputs:
Number of Inputs:
2
Connectors: Female XLR and 1/4” TRS
Type: Electronically balanced/unbalanced, RF filtered
Impedance: Balanced 50kΩ, Unbalanced 25kΩ
Max input line level: +20dBu
CMRR: >40dB, typically >55dB @ 1kHz
Analog Outputs:
Number of Outputs:
2
Connectors: Male XLR and 1/4” TRS
Type: Electronically balanced/unbalanced, RF filtered
Impedance: Balanced >120Ω, unbalanced >60Ω
Max Output Level: +20dBu
A/D Performance:
Type:
dbx Type IV™ conversion system
Dynamic Range: >113dB A-weighted, >110dB unweighted, 22kHz BW
Type IV™ dynamic range: >119dB, A-weighted, 22kHz BW
>117dB, unweighted, 22kHz BW
A/D Conversion: 24 bit
D/A Performance:
Dynamic Range:
112dB A-weighted, 109dB unweighted
D/A Conversion: 24 bit
System Performance:
Sample Rate:
48kHz
Dynamic Range: >109dB A-weighted, >106dB unweighted, 22kHz BW
THD+N: 0.003% typical at +4dBu, 1kHz
Frequency Response: 20Hz – 20kHz, +/- 0.5dB
Interchannel Crosstalk: >80dB typical
Crosstalk input to output: >80dB typical
Operating Voltage: 100VAC 50/60Hz, 120VAC 60Hz and 230VAC 50/60Hz
Power Consumption: 9 Watts
Safety Agency Approvals:
UL 6500, IEC 60065, EN 55013, E 60065
