AFS™ 224 User Manual
Selecting the Number of Fixed Filters
When in Setup Mode, use the channel
button(s) to toggle to the Set Number Fixed Filters
Menu indicated by the selected channel’s
button lighting green. The current setting for the
number of Fixed filters is indicated by the number of
Filter LED’s lit for each channel.
To change the number of Fixed filters, use the
selected channel’s
to increment and the
the number of filters. Each press of the button will
increment or decrement the total number of Fixed
filters. Press and hold each button to slowly increment
or decrement the number.
WARNINg!
Changing the number of Fixed filters
may remove feedback filters already set.
Green
12 Fixed Filters
Allocated
+
Green
-
Fixed Filters
Available
Exiting Setup Mode
To exit Setup Mode and return to Normal Operating
Mode, press and hold the CHANNEL ONE
from left to right, then release the button (same as
entering Setup Mode).
Operation
