AFS™ 224 User Manual
Technical Information
Factory Hard Reset
In the event that you would like to set all parameters back to their factory default state, please perform the
Factory Hard Reset procedure outlined below.
WARNINg! Performing this reset will clear all set filters. Ensure the system’s gain is reduced and
amplifiers are off before performing this procedure to ensure the system does not go into feedback once
the filters are cleared.
Step 1. Power on the unit while pressing and holding both
channel’s buttons until the
CHANNEL ONE and CHANNEL TWO INPUT
LEVEL meters display the LED pattern shown on the
right, then release the buttons.
Step 2. The CHANNEL ONE button LED should
now be lit red. All other LEDs should be off.
Step 3. Press and hold the CHANNEL TWO button until all button LEDs flash, then
release the button.
Step 4. Press and hold the CHANNEL ONE button until all button LEDs flash again,
then release the button.
All settings will now be back to their factory default state and the unit is now ready to operate. The AFS
224’s factory default settings are as follows:
Parameter Default Value
Total Number of Filters 24
Fixed Filters 12
Live Filters 12
Channel Link/Unlink Unlinked
Front Panel Lockout Unlocked
Bypass On
Type Music High
Live Filter Lift Time 10 Minutes
Mode Live
