1
SPECIFICATIONS
Notes:
1. Specifications subject to change without notice.
2. Legal requirements may exist regarding permission to connect equipment to a
Telecom network operated by a public network operator.
Parameter Working limits
ELECTRICAL
Rotary dial output
Pulsing rate
Percent break
Inter digit interval
Leakage break 10pps + 0.8pps
61%±2%
1000 ms typical
>50 KΩ
DTMF output
Tone frequency error
Tone level
High versus low tone difference ±1.2% maximum
-8 ±2dBm combined(typical)
4 dB maximum
Memory Dialing
Memory capacity
Digit capacity
PBX pause 16 memories plus last number redialing
16 digits per memory
4 seconds
Caller ID
Memory capacity
Digit capacity 62 memories
12 digits per memory
Volume levels Low, high
LCD brightness level 5
Extension port RJ-45 x 1
Power source 3 x 1.5V AAA batteries (not include)
PHYSICAL
Length 156 mm
Width 55.3 mm
Height 31.5 mm
Weight 211.8g
