7
Range Accuracy Resolution
600mV
±(0.5%+4d)
0.mV
6V mV
60V 0mV
600V 00mV
000V ±(1.0%+4d) V
• Input impedance: 600mV range>60MΩ, the others are 10MΩ. Overload protection:
000VDC or 750V alternative peak.
AC Voltage (ACV)
. Circularly press the “AC/DC” key until
it selects the AC Voltage automatic
measurement mode. Meanwhile, the
symbol “AC”,“AUTO”,“APO” will appear
on the LCD. Respectively plug in the
red and black meter pens into the terminals
of “
VΩ Hz
TEMP ” and “com”. See the picture re below.
2. The initial state of the meter is automatic range,
which shows “AUTO” symbol. Press the “Range” key and switch it to manual range
mode. In the AC mode of automatic/manual range, the frequency/ duty cycle can be
measured by pressing “Hz/DUTY”. However, the frequency response now is low ,
which is suitable for the measurement of high voltage and low frequency in the envi-
ronment of magnetic field interference such as 220V/50Hz-400Hz,380V/50Hz-400Hz.
Caution:
Voltages over DC000V or AC750V cannot be tested. In case “OL” is displayed for
manual range mode, it indicated the range has been exceeded and it is necessary to
select higher range mode to complete this measurement.
Range Accuracy Resolution
6V
±(0.8%+10d)
mV
60V 0mV
600V 00mV
750V ±(1.0%+6d) V
CAT ll
VΩ Hz
10A
COM mA
10A 10sec MAX FUSED
MAX 600mA
FUSED MAX 1000V DC 750V AC
Ω
m A
A
DC
/A C Hz/
C˚/F
˚
AUTO POWER OFF
POWER REL/RS232
MAX/MIN Hz/DUTY HOLD RANGE
TEMP
DC
V
AUTO
APO
V~
y
X
60Hz
Voltage
switch
CAT ll
VΩ Hz
10A
COM mA
10A 10sec MAX FUSED
MAX 600mA
FUSED MAX 1000V DC 750V AC
Ω
m A
A
DC
/A C Hz/
C˚/F
˚
AUTO POWER OFF
POWER REL/RS232
MAX/MIN Hz/DUTY HOLD RANGE
TEMP
DC
V
AUTO
APO
Voltage
switch
