Figure 4 - Spare Parts
8. With faucet in the OFF position, open water supply valves. Inspect connections under sink for leaks. DO
NOT turn faucet on yet.
9. Pull SPRAYHEAD (5) out from SPOUT (4). While holding HOSE (6), unscrew
SPRAYHEAD (5). Aiming HOSE (6) into sink, turn on faucet to center position
(mixed) and flush for one minute to remove debris from lines.
10. Turn OFF faucet and reattach SPRAYHEAD (5) to HOSE (6). See Figure 5.
11. Check the SPRAYHEAD (5) by operating the trigger from aerator to spray.
4
6
5
Figure 5
01/28/14
ORDER 11870
FOR 1500-5203
