Newport Brass 130 Brasstech User Manual
Installation instructions
Installation Instructions:
Recommended installation by a Professional Plumbing Contractor
1. Disconnect and remove existing flange / strainer assembly from drain pipe.
2. Place gasket onto drain flange, clear silicone sealant may be used in place of
gasket. Place the drain flange in sink hole.
3. From underside of sink, place additional gasket onto flange and secure with
flange nut.
4. Attach flange to existing tailpiece drain pipes with slip nut and washer pro-
vided.
5.Test seal by running water and make adjustments as required.
JUNIOR BASKET STRAINER INSTALLATION INSTRUCTIONS
MODEL No's: 130
BASKET STRAINER
DRAIN FLANGE
GASKET
SINK
GASKET
FLANGE NUT
SLIP NUT
BRS-130
9/29/05
WASHER
