7-43
2. Dotted lines in the illustration show
center of headlights.
“H”;
Horizontal center line of headlights
from ground : 628 mm (24.72 in)
“W”;
Distance between each headlight
center: 1,306 mm (49.17 in)
“L”;
Distance between the headlights and
the wall that the lights are tested
against: 3,000 mm (118.11 in)
