7-13
3. Remove the engine oil filter with an
oil filter wrench.
4. Use a clean rag to clean the oil filter
mounting surface on the engine.
5. Apply a small amount of engine oil
to the new oil filter O-ring seal.
6. Install the oil filter and tighten it.
(Refer to the oil filter caution label
for tightening instructions.)
7. Replace the drain plug tightly after
the oil has thoroughly drained.
8. Refill the engine with new oil to the
F mark on the dipstick. Do not
overfill.
9. Re-install the oil filler cap securely.
10. Start the engine and inspect around
the oil filter seal for leaks.
Stop the engine.
Check the oil level and fill to the F
mark, if necessary.
OIL CAPACITY
• 2400cc Engine
- Without filter change : 4.0 liters
- With filter change : 4.3 liters
• 2700cc Engine
- Without filter change : 4.5 liters
- With filter change : 4.8 liters
Use only the specified engine oil. (Refer
to “Recommended Lubricants” later in
this section)
CAUTION
Both the oil and engine are hot. Do
not burn yourself.
✻ NOTICE
When installing the replacement oil
filter, do not allow the oil filter
gasket to remain on the oil filter
mounting surface. This will cause
oil leakage and engine damage.
Remove the old gasket completely
so that a new gasket will properly
seat and seal.
✻ NOTICE
• Follow these instructions
carefully. An improper oil filter
installation can cause oil leakage
and engine damage.
• Although oil filters may have the
same external appearance, their
internal designs differ
significantly. These filters are not
interchangeable. To avoid
potential engine damage, use only
the specified filter. Consult an
Authorized Kia Dealer.
