DRIVING YOUR VEHICLE
4-42
CLIMATE CONTROL
SYSTEM
CONTROLS
A : Fan speed control knob
B : Mode selection
C : Temperature control knob
D : Air conditioning switch
E : Air intake control switch
F : Rear window defroster switch
G : MAX A/C mode switch
FAN SPEED CONTROL KNOB
The fan speed control knob (A) is the
knob closest to the driver. Four (4)
adjustable fan speeds are provided which
increase as the number increases. The
ignition switch must be in the ON
position for fan operation.
OFF - Fan off
1
- Low speed
2 - Medium speed
3 - High speed
4 - Maximum speed
MODE SELECTION
It controls the direction of air flow
through the ventilation system.
The air from outlet port D flows at any
mode. Close the ventilation outlets using
the knob to block the air flow if you do
not want the air.
1
2 3 4
0
MAX
A/C
MMSA4044A
MMSA4050
E D F
A B C
G B
B
C
C
D
D A
A
A A
