USB Rover 1650/2650
6
With Premise Cabling
1. Plug one end of a Category 5 patch cord (not included) into the
Link port on the LEX unit.
2. Plug the other end of the patch cord into the Category 5 information
outlet near the host computer.
3. Plug one end of the second Category 5 patch cord (not included)
into the Link port on the REX unit.
4. Plug the other end of the second patch cord into the Category 5
information outlet near the USB device.
NOTE : The maximum length of the Category 5 UTP cable, including patch
cords, must not exceed 50 meters.
Checking the Installation
1. Check that the Link LEDs on both LEX unit and REX unit are on.
Connecting a USB Device
1. Install any software required to operate the USB device. Refer to
the documentation for this device, as required.
2. Connect the USB device to the Device port on the REX unit.
3. Check that the Host LED on LEX unit is on.
4. Check that the Device LED on REX unit is on.
