Step 1: Click insert slave button
in the PROFIBUS
configuration tool.
Step 2: Choose GW-7553 device
and click Add button.
Step 4: Finish adding GW-7553
in the DP-master
Step 3: Set address of GW-7553
and then click OK button.
¾ Set the parameters of the GW-7553
The user needs to change “Modbus Type” to Slave, “Modbus Format” to
Modbus TCP and use the default value in the other parameters in this
example. Please refer to user manual section 4.3 The Configuration of the
common parameters.
Double click the GW-
7553’s icon to enter the
Slave configuration dialog Click button
to enter the Parameter Data
dialog
GW-7553 PROFIBUS/Modbus TCP Gateway Quick Start (Version 1.00, DEC/2008) PAGE：4
