Hardware Overview
Manual Documentation Number ES1A -5012m pn6909-rev003 3
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
C C h h a a p p t t e e r r 2 2 : : H H a a r r d d w w a a r r e e O O v v e e r r v v i i e e w w
Package Checklist
ES1A Ethernet to RS-232 Converters are shipped with the following items
included:
 The ES1A module
 5VDC 500mA 5.5mm by 2.1mm tip positive barrel jack power supply.
 A printed version of this user manual
 A printed version of the ES1A Quick Start Guide
 CD-ROM disc with
o B&B discovery software
o RealPort drivers for Windows 98/ME/2000/XP/NT 4.0/Vista
o this user manual in PDF format
o a Quick Start guide in PDF format
Figure 2. Top View of the ES1A Converter
