(Revised 8/5/2009) 2
Industrial Gigabit Ethernet Switch Installation Guide
1002MC-SX 1000BaseSX multimode fiber media converter
1002MC-LX-YY 1000BaseLX singlemode fiber media converter
1003GX2-SX 1000BaseSX multimode fiber switch
1003GX2-LX-YY 1000BaseLX singlemode fiber switch
1003GX2-B Custom mix and match 1003GX2 switch
1005TX 5 port gigabit Ethernet switch
Where "YY" is: 10 for 10km max. fiber segment length
40 for 40km max. fiber segment length
70 for 70km max. fiber segment length
1003GX2-B SFP (Mini-GBIC) Fiber Transceivers:
NTSFP-SX (LC Style Connector, up to 550m)
NTSFP-LX-10 (LC Style Connector, up to 10km)
NTSFP-LX-40 (LC Style Connector, up to 40km)
NTSFP-LX-70 (LC Style Connector, up to 70km)
