7
SPECIFICATIONS
Fiber Connections:
Multi-mode 1300nm Dual Fiber
Single-mode 1310nm 1550nm Dual Fiber
Single-mode 1310nm 1550nm Single-Strand Fiber
Ethernet Connections:
• 10/100/1000 BaseT
• Auto-Negotiation
• Auto-Cross
• Flow Control
• 1632 MTU
• Full Line-Rate Forwarding
DC Input Voltage:
7 to 50 VDC on DC terminal block
5 VDC on DC jack
AC Wall Adapter:
100 to 240 ±10% VAC input, 5 VDC output, 2 A max.
Power Consumtion
600 mA
Operating Temperature:
-31° to 158° F (-35° to 70° C) DC terminal block
32° to 122° F (0° to 50° C) with IMC supplied AC wall adapter
Storage Temperature:
-31° to 167° F (-35° to 75° C)
Humidity:
5 to 90% (non-condensing); 0 to 10,000 ft. altitude
Dimensions:
0.83”H x 1.80”W x 3.35”D (2.11 x 4.57 x 8.51 cm)
iii
TABLE OF CONTENTS
FCC Radio Frequency Interference Statement ....................................................ii
Warranty............................................................................................................ii
Introduction to the IE-Giga-MiniMc....................................................................1
Installing the IE-Giga-MiniMc .............................................................................2
Powering the IE-Giga-MiniMc ............................................................................3
DC Power Supply Precautions............................................................................5
Operating the IE-Giga-MiniMc ...........................................................................5
Reading the LEDs...............................................................................................6
IMC Networks Technical Support.......................................................................6
Specifications .....................................................................................................7
Safety Certifications............................................................................................8
