Product overview

background image

Product Overview

SMA Antenna
connector

LEDs

3 V or 1.8 V
SIM card
readers

SMA Antenna
connector

Power

Ethernet
and/or
Aux ports

USB Port

I/O Port

The router will not work unless an antenna is attached,

power is applied, and an activated SIM card is inserted.

Register your Jazz card

Powering the router with no antenna
attached can damage the router

Use the following link:

https://prepaid.jazzwirelessdata.com/prepaid/#

If you have an existing account, please login and

proceed to Step 2.

If you do not have an existing, account please

click “Register” to create an account.

Enter your personal information and create a

password. When entering your SIM card

number(s), use the 19 digit number located on the

bottom left of the card.

Do not include the letter (F) at the end of the number.

1

2

Digi-Key Sample SIM Activation Portal

Enter the activation code (key) 41295876. Then

press “Submit.”

Now check your email, where you will have

received a link to complete activation. The link will

send you to the login screen. Log in and proceed to

Step 2.

Note: The “username” is the email address supplied
during registration.

To add additional SIM(s), click “Register SIMs”.

The link is located at the bottom right corner of

the table.

If you see red text, as shown in the screen

captures below, please wait for the SIM card to

fully register with JAZZ. You may need to

manually refresh the page.

SIM Registration page shows red text
