Frequently Asked Questions
Please visit Icron’s website for answers to FAQs: http://www.icron.com/products/usb/faq.php
Specifications
Maximum range 40 metres (132 ft)
Cable characteristics Riser jacket of retardant PVC with 4 strands of
multimode fibre of dimension 62.5/125 µm
Tensile strength: 1200N
Minimum bend radius: 6.8 cm
USB device support 1 x full-speed (12 Mb/s) or low-speed (1.5 Mb/s) device
USB hub support Conventional USB hubs may be connected in series with the USB
Rover 200. The maximum number of such hubs is:
1 metre cables: 4 hubs 30 metre cables: 2 hubs
10 metre cables: 4 hubs 40 metre cables: 1 hub
20 metre cables: 3 hubs
Maximum power available to USB at REX unit 500 mA
Power adapter capacity 5V DC @ 2.6A (connected at REX)
Current available to USB at REX 1 x USB Type A connector
LEX unit connector (upstream) 1 x USB Type A port
REX unit connector (downstream) 73mm x 23mm x 12mm / 2.875” x 0.875” x 0.5”
LEX unit dimensions 73mm x 23mm x 12mm / 2.875” x 0.875” x 0.5”
Total system shipping weight 1 m: 0.57 kg / 1.2 lb 30 m: 1.26 kg / 2.8 lb
10 m: 0.75 kg / 1.6 lb 40 m: 1.53 kg / 3.37 lb
20 m: 1.05 kg / 2.2 lb
Temperature range -10°C to 55°C
Regulatory testing FCC, CE Class B
