2
Managed Modules
To manage one or more iMcV-MediaLinX Modules, an SNMP agent must be present
in the chassis: The iMediaChassis series requires an SNMP Management Module. To
configure Managed Modules, install the module first, and then configure using the
management software. All fiber type information is now loaded into a NVRAM
during manufacturing. This is viewed only via iView² software, within the modules
details.
Requirements:
• SNMP Firmware version C2
• iView² 1.8.6 or higher
NOTE
If the module is going to be managed via the software management, configuration settings
will override any hardware settings, such as DIP Switches or jumpers.
Unmanaged Modules
Before installing, configure iMcV-MediaLinX Modules for desired features listed in the
table below. After configuring the DIP Switches for the desired settings, install the
module and connect the appropriate cables. For further information, refer to the
Installing an iMcV Module section.
DIP Switch on
S1
Feature DIP Switch Options Default Setting
1 Auto Negotiation ON ON
2 TX FDX OFF OFF
3 TX 100Mbps ON OFF
TX 10Mbps OFF OFF
4 TX LinkLoss OFF OFF
5 FX LinkLoss ON OFF
6 FX FDX OFF OFF
FX HDX ON OFF
7 FiberAlert OFF OFF
8 Selective Advertising OFF OFF
9 Far End Fault OFF OFF
10 Flow Control OFF OFF
BEST PRACTICES
When possible, it is always a good idea to configure DIP Switches to match software settings.
