4
DIP Switch Settings
FUNCTION SWITCH SET RESULT [(D) = Default]
Loopback (iView
2
Configurable)
S1-1: OFF Loopback Disabled (D)
S1-1: ON Loopback Enabled
Loopback Type (iView 2 Configurable)
S1-2: OFF Coax (D)
S1-2: ON Fiber
Reserved
S1-3: OFF
S1-3: ON
Fault Loopback (iView 2 Configurable)
S1-4: OFF Fault loopback Disabled
S1-4: ON Fault loopback Enabled (D)
Line Build-Out
S1-5: OFF 0 to 255 ft. (D)
S1-5: ON > 255 ft.
Transmit Coax Data Source (iView 2 Configurable)
S1-6: ON 7: ON Standard Data (D)
S1-6: OFF 7: ON Unframed All Ones
S1-6: ON 7: OFF Alternating Ones & Zeros
S1-6: OFF 7: OFF Pseudorandom Bit Sequence
DS3/E3/STS/STS Selection
S1-8: ON 9: OFF 45 Mbps (DS3) (D)
S1-8: OFF 9: ON 34 Mbps (E3/STS)
S1-8: ON 9: ON 52 Mbps (STS)
Remote Management
S1-10: OFF Remote Management Disabled (D)
S1-10: ON Remote Management Enabled
Installation
iMcV-DS3/E3/STS-LineTerm modules can be installed in any iMediaChassis or
MediaChassis series, but can be managed only through the iMediaChassis. Each
module requires one slot in the chassis. To install a module, remove the blank
brackets covering the slots where the module is to be installed by removing the
screws on the outside edges of the bracket. Slide the module into the chassis card
guides, until the module is securely seated in the connector. Secure the module to
the chassis by tightening the captive screw. Save any blanks removed during
installation for future use.
NOTE
It is not recommended that the iMcV-DS3/E3/STS-LineTerm module be installed in an IE-
MediaChassis/1-DC chassis (850-33100). The power source in this chassis is not isolated and
cannot support positive referenced ground systems typically used in Telco environments. The
IE-MediaChassis/2-DC and the iMediaChassis/6-DC are suitable alternatives.
