3

DIP Switches

The iMcV-DS3/E3/STS-LineTerm DIP Switches are located at S1 and S2 on the PCB.
The S2 DIP Switches are factory configured and must not be changed. The S1 DIP
Switches provide control over the available iMcV-DS3/E3/STS-LineTerm features.

The location of the S1 DIP Switches is displayed in the following diagram:
