Quick Start Guide Documentation Number: ESW200series-1112qsg 1

B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com

B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com

Chapter 1

– Introduction

Description


The ESW205/208 series are plug-and-play, Class 1 Div 2, heavy Industrial
Ethernet switches with a compact IP30 DIN rail case. Switch
configurations support 5 and 8 ports, all copper or with ST, SC fiber ports.

They will support IEEE 802.3 for 10BaseT (10 Mbps), IEEE 802.3u for
100BaseTX and 100BaseFX (100 Mbps), and IEEE 802.3x, 10/100 Mbps,
full and half duplex, MDI/MDX auto sensing.

The ESW205/208 series uses dual power inputs that accept 12 to 36 VDC
or 10 to 24 VAC with removable terminal blocks. The acceptable
operating temperature range is -10C to 60C or (-T models) -40 to 75°C with
an ambient relative humidity rating of 10 to 95% (Non-condensing).

The ESW205/208 series has 7 different mounting options. One being din
rail and 6 different panel mounted options. Panel mount adapters are
shipped with switches.

Package Checklist


The ESW205/208 will ship with the following items.

B&B Ethernet switch with attached din rail clip

Quick Start Guide

4 - Panel mount clips with screws
