Page 11: Din rail mounting
Quick Start Guide Documentation Number: ESW200series-1112qsg 7
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
LED Indicators
LED
Status
Description
PWR
Green ON
Power Applied
Off
No power
Speed LED
Green ON 100Mbps
Off
10Mbps
Link / Activity LED
Green ON Link
Blinking
Activity
Off
Not connected to network
Fiber LED
Green ON Link
Blinking
Activity
Off
Not connected to network
Din Rail Mounting
The din rail mounting clips are connected to the switch when shipped and
ready to be mounted on a
35mm size din rail.
