LED Indicators
Note: In order for the RSSI LED to continuously indicate the signal strength, set the
“RP” command (RSSI PWM Timer) to FF.
Radio Frequency Information
The ZP24D-250RM-SR has an indoor range up to
300 feet and an outdoor range up to one mile.
These ranges are for line of sight installations using
the supplied antenna. Performance may vary
depending on your particular installation.
The antenna connection on the radio modem is an
RPSMA female plug.
B&B Electronics has a wide variety of accessory
antennas. Visit www.bb-elec.com for more
information.
Front Panel LED Status
Power Red = ON
OFF = No Power
RSSI (Signal Strength) Green = Strong
Yellow = OK
Red = Weak
OFF = No Signal
Wireless Data Green = Blink ON with
data
Model # Frequency Radio
Power RF Data
Rate
ZP24D-250RM-SR 2.4GHz Configurable
Up To
100mW 250Kbps
