Using configuration utilities ExpressCard Parallel Port Adapter User’s Manual
Page 16 Rev 1.00 (July 2007)
Figure 17 - Windows XP Device Manager - Adapter properties, Driver tab
Step Procedure Description

Step 6 Click the Driver tab to view the driver
information and update the driver. The ExpressCard Parallel Port Driver
properties dialog box displays.

Step 7 You have several options:
 View detailed driver information
 Update the device drivers
 Uninstall your Parallel Port Adapter.
 Return to the previously installed
driver.
 Save your changes and exit.
Abandon your changes and return to the
Device Manager.
See below.

Step 8 Click the Driver Details button to view
detailed driver information. The Driver File Details dialog box opens.
See the following figure.
Figure 17 illustrates the
Adapter Properties, Driver
Tab, which lets you view the
driver details and update, roll
back, or uninstall the driver.
