AM Series Pushbutton Enclosures:
Inline Lift-Off Screw Cover
A P P L I C A T I O N
• Designed to insulate and house pushbuttons and switches in applications that require
a human-machine interface
• Especially well suited for high temperature or corrosive environments
• Protects from dirt, dust, oil and water
• For use with industrial control equipment in ordinary locations
S T A N D A R D S
• Construction meets NEMA/EEMAC Type 4, 4X, 12 specifications
• UL 508 listed, Type 1, 2, 3, 3R, 4, 4X, 12, 13
• CSA certified LR 89590 for use with industrial control equipment CSA Enc. 1, 2, 3, 4, 4X, 12, 13
C O N S T R U C T I O N
• Rugged, molded fiberglass reinforced polyester construction with reinforced corners
• Available with either 30.5mm or 22.5mm holes
• 304 stainless steel captive cover screws
• “Tongue and groove” type closed-cell neoprene gasket
• Grounding strap included
• UV stabilized for outdoor use
M O D I F I C A T I O N S
• Molded-in color matches
• EMI/RFI shielding
• Factory-supplied silk screening
