Quick Start Guide Documentation Number: ESW100series-1112qsg 1
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com1
Chapter 1
– Introduction
Description
The ESW105/108 series are plug-and-play, Class 1 Div 2, Heavy Industrial Ethernet
Switches with an ultra compact IP30 DIN rail case. Switch configurations support 5
and 8 ports, all copper or with one LC fiber.
They will support IEEE 802.3 for 10BaseT (10 Mbps), IEEE 802.3u for 100BaseTX
and 100BaseFX (100 Mbps), and IEEE 802.3x, 10/100 Mbps, full and half duplex,
MDI/MDX auto sensing.
The ESW105/108 series uses dual power inputs that accept 12 to 36 VDC or 10 to 24
VAC with removable terminal blocks. The acceptable operating temperature range is
-10C to 60C with an ambient relative humidity rating of 10 to 95% (Non-condensing).
The ESW105/108 series has 7 different mounting options. One being din rail and 6
different panel mounted options. Panel mount adapters are shipped with switches.
Package Checklist
The ESW105/108 will ship with the following items.
B&B Ethernet switch with attached din rail clip
Quick Start Guide
4 - Panel mount clips with screws
