LED Indicators
LED
Status
Description
PWR
Green ON
Power Applied
Off
No power
10/100 Copper Upper LED
Green ON 100Mbps
Off
10Mbps
10/100 Copper Lower LED
Green ON Link
Blinking
Activity
Off
Not connected to network
Fiber LED
Green ON Link
Blinking
Activity
Off
Not connected to network
Din Rail Mounting
The din rail mounting clips are connected to the switch when shipped and ready to be
mounted on a
35mm size din rail.
