Documentation Number 232MSS2-0812 Manual Appendix B B-5
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445
Chart 7. IBM PC DB9 Connector to Ports A - D (DCE)
Master port configured as a DTE port.
IBM PC
Serial Port
DB9 Connector
Signal
Direction
232MSS2
Ports A - D (DCE)
DB9 Connector
1 <----------- 4*
2 <----------- 2
3 -----------> 3
4 -----------> 4*
5 <---------> 5
6 <----------- 6*
7 -----------> 7
8 <----------- 8
* Pins are tied together inside the 232MSS2, they are not connected
to the master port.
Chart 8. IBM PC DB25 Connector to Ports A - D (DCE)
Master port configured as a DTE port with a modem connected
(see Chart 3).
IBM PC
Serial Port
DB25 Connector
Signal
Direction
232MSS2
Ports A - D (DCE)
DB9 Connector
2 -----------> 3
3 <----------- 2
4 -----------> 6*
5 <----------- 4*
6 <----------- 4*
7 <---------> 5
8 <----------- 8
20 -----------> 7
* Pins are tied together inside the 232MSS2, they are not
connected to the master port.
