Documentation Number 232MSS2-0812 Manual 7
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445
Programming the Second Character
The second character comes programmed as the ASCII STX
character (decimal 2). You can change this to any 8-bit character you
wish by reprogramming dipswitch “SW2”. “SW2” is an eight-position
switch with each position equal to a certain weight. Refer to “Setup”
for instructions on removing the cover to access “SW2”. Table 4
shows the weight chart for “SW2”.
*Factory Default --
ASCII “STX” character
(decimal 2), SW2 position 2 is only one ON.
If you wish to use the letter "U" as the second character, which
has a decimal value of 85, you would turn on switches 1, 3, 5, and 7
(1 + 4 + 16 + 64 = 85). Caution should be used when selecting the
second character, so that by itself, or with the ESC character in front
of it, it is not a valid command to any of the devices on the port. For
instance, on some printers ESC @ is the reset command. If you tried
to use the @ symbol (decimal 64) for the second character you could
reset your printer every time the preamble code was sent. Also, if
your communication configuration is set for 7 data bits you cannot
use the eighth bit of SW2. For a list of the ASCII character codes
and their decimal values, refer to Appendix A.
Binary File Transfer
A simple method of using the Mini Smart Switch to transfer
binary files without the concern of it accidentally disconnecting, is to
set the file transfer at a different baud rate from the rate of the Mini
Smart Switch. When transferring files at a different baud rate, the
Mini Smart Switch will stay connected from the last preamble code.
Table 4. Programmable Character Setting
Dipswitch SW2* WEIGHT
1 1
2 2
3 4
4 8
5 16
6 32
7 64
8 128
