Specifications
Range Up to 100m (330 ft)
USB Device Support & Throughputs USB 3.0 up to 5Gbps
USB Host Support xHCI controllers (Intel, AMD, Renesas (NEC), Fresco, AsMedia)
AC Adapters 100-240V AC Input, 5V DC Output, Locking
Power Available to USB Device at REX 900mA for each USB Port
Enclosure Material Anodized Aluminum
LOCAL EXTENDER (LEX)
USB Connector 1 x USB 3.0 Type B Locking Receptacle
Link Connectors 1 x Duplex LC Connector
Dimensions 100mm x 76mm x 26mm (3.94” x 2.99” x 1.02”)
REMOTE EXTENDER (REX)
USB Connectors 2 x USB 3.0 Type A Locking Receptacles
Link Connectors 1 x Duplex LC Connector
Dimensions 100mm x 76mm x 26mm (3.94” x 2.99” x 1.02”)
ENVIRONMENTAL
Operating Temperature Range 0°C to 40°C (32°F to 104°F)
Storage Temperature Range -20°C to 70°C (-4°F to 170°F)
Operating Humidity 20% to 80% relative humidity, non-condensing
Storage Humidity 10% to 90% relative humidity, non-condensing
COMPLIANCE
EMC FCC (Class B), CE (Class B)
Machine Vision AIA USB3 Vision (upon standard release)
Environmental RoHS2
SUPPORT
Warranty 2 years
18
