DS1689/DS1693
8 of 32
TIME, CALENDAR AND ALARM DATA MODES Table 1
RANGE
ADDRESS
LOCATION
FUNCTION
DECIMAL
RANGE
BINARY DATA
MODE
BCD DATA
MODE
00H Seconds 0-59 00-3B 00-59
01H Seconds Alarm 0-59 00-3B 00-59
02H Minutes 0-59 00-3B 00-59
03H Minutes Alarm 0-59 00-3B 00-59
Hours 12-hr Mode 1-12 01-0C AM, 81-8C PM 01-12 AM, 81-92 PM 04H
Hours 24-hr Mode 0-23 00-17 00-23
Hours Alarm 12-hr
Mode 1-12 01-0C AM, 81-8C PM 01-12 AM, 81-92 PM 05H
Hours Alarm 24-hr
Mode 0-23 00-17 00-23
06H Day of Week
Sunday=1 1-7 01-07 01-07
07H Date of Month 1-31 01-1F 01-31
08H Month 1-12 01-0C 01-12
09H Year 0-99 00-63 00-99
BANK1, 48H Century 0-99 00-63 00-99
BANK 1, 49H Date Alarm 1-31 01-1F 01-31
CONTROL REGISTERS
The four control registers; A, B, C, and D reside in both bank 0 and bank 1. These registers are accessible
at all times, even during the update cycle.
NONVOLATILE RAM - RTC
The 114 general-purpose nonvolatile RAM bytes are not dedicated to any special function within the
DS1689/DS1693. They can be used by the application program as nonvolatile memory and are fully
available during the update cycle. This memory is directly accessible when bank 0 is selected.
INTERRUPT CONTROL
The DS1689/DS1693 includes six separate, fully automatic sources of interrupt for a processor:
1. Alarm interrupt
2. Periodic interrupt
3. Update-ended interrupt
4. Wake-up interrupt
5. Kickstart interrupt
6. RAM clear interrupt
The conditions, which generate each of these independent interrupt conditions, are described in greater
detail elsewhere in this data sheet. This section describes the overall control of the interrupts.
