DS1689/DS1693
31 of 32
DS1689S 28-PIN SOIC
PKG 28-PIN
DIM MIN MAX
A IN.
MM
0.697
17.70 0.728
18.50
B IN.
MM
0.324
8.23
0.350
8.90
C IN.
MM
0.087
2.20
0.118
3.00
D IN.
MM
0.016
0.40
0.050
1.27
E IN.
MM
0.002
0.05
0.014
0.35
F IN.
MM
0.100
2.55
0.120
3.05
G IN.
MM
0.050 BSC
1.27 BSC
H IN.
MM
0.453
11.50 0.500
12.70
J IN.
MM
0.006
0.14
0.013
0.32
K IN.
MM
0.014
0.35
0.020
0.50
