MAX3580
Direct-Conversion TV Tuner
6 _______________________________________________________________________________________
TEST SCENARIO COMMENTS SPEC MINIMUM MAX3580 TYPICAL
MBRAI S2 Immunity/ACPR for N ±1 adjacent ch. 29dB 40dB
MBRAI S2 Immunity/ACPR N ±2 alternate ch. 40dB 43dB
MBRAI L3 Li near ity/cr ossm od . w i th N +2 and N +4 ch. 40dB 47dB
NorDig 16 QAM 2/3 S ensi ti vi ty at channel 21 ( 470 M H z) -84.1dBm -85.1dBm
NorDig QPSK 1/2 Sensitivity at channel 42 (642 MHz) -92.1dBm -94.8dBm
NorDig 64 QAM 7/8 Sensitivity at channel 59 (778 MHz) -74.7dBm -76dBm
Performance to Standards
The following is selected overall performance data for the
MAX3580 + digital demodulator.
Table 1 shows the typical overall performance as mea-
sured using the MAX3580 and one current production
DVB-T demodulator. This reference design is available
in NIM card form factor upon request.
MBRAI refers to standard MBRAI 04-102 IEC 62002-1
available from www.ansi.org.
NorDig refers to standard Unified 1.0.2 available from
www.nordig.org.
Modulation of wanted and interfering channel(s) is 8k
mode, 16 QAM, C/R = 3/4, GI = 1/4, sensitivity or
immunity Reference Bit Error Rate is 2 x 10e-4, unless
stated otherwise.
Table 1. Selected Typical MBRAI and NorDig Performance
