MAX1421

12-Bit, 40Msps, +3.3V, Low-Power ADC
with Internal Reference

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(V

AVDD

= V

DVDD

= +3.3V, AGND = DGND = 0, V

IN

= ±1.024V, differential input voltage at -0.5dB FS, internal reference,

f

CLK

= 40MHz (50% duty cycle), digital output load C

L

≈ 10pF, T

A

= T

MIN

to T

MAX

, unless otherwise noted. Typical values are at

T

A

= +25°C.)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

AV

DD

, DV

DD

to AGND ..............................................-0.3V to +4V

DV

DD

, AV

DD

to DGND..............................................-0.3V to +4V

DGND to AGND.....................................................-0.3V to +0.3V
INP, INN, REFP, REFN, REFIN,

CML, CLK, CLK,....................(AGND - 0.3V) to (AV

DD

+ 0.3V)

D0–D11, OE, PD .......................(DGND - 0.3V) to (DV

DD

+ 0.3V)

Continuous Power Dissipation (T

A

= +70°C)

48-Pin TQFP (derate 12.5mW/°C above +70°C)........1000mW

Maximum Junction Temperature .....................................+150°C
Operating Temperature Ranges

MAX1421CCM ...................................................0°C to +70°C
MAX1421ECM ................................................-40°C to +85°C

Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

DC ACCURACY

Resolution

RES

12

Bits

T

A

= +25

°C, no missing codes

-1

1

Differential Nonlinearity

DNL

T

A

= T

MIN

to T

MAX

±0.5

LSB

Integral Nonlinearity

INL

T

A

= T

MIN

to T

MAX

±2

LSB

Mid-scale Offset

MSO

-3

±.75

3

%FSR

Mid-scale Offset Temperature
Coefficient

MSOTC

3

10

-4

%/

°C

Internal reference (Note 1)

-5

0.1

5

External reference applied to REFIN (Note 2)

-5

±3

5

Gain Error

GE

External reference applied to REFP, CML,
and REFN (Note 3)

-1.5

±0.5

1.5

%FSR

Gain Error Temperature
Coefficient

GETC

External reference applied to REFP, CML,
and REFN, (Note 3)

15

10

-6

%/

°C

DYNAMIC PERFORMANCE (f

CLK

= 40MHz, 4096-point FFT)

f

IN

= 5MHz

67

Signal-to-Noise Ratio

SNR

f

IN

= 15MHz, T

A

= +25

°C

62

66

dB

f

IN

= 5MHz

73

Spurious-Free Dynamic Range

SFDR

f

IN

= 15MHz, T

A

= +25

°C

64

70

dBc

f

IN

= 5MHz

-74

Total Harmonic Distortion

THD

f

IN

= 15MHz, T

A

= +25

°C

-69

-62

dBc

f

IN

= 5MHz

66

Signal-To-Noise Plus Distortion

SINAD

f

IN

= 15MHz, T

A

= +25

°C

60

63.5

dB

f

IN

= 5MHz

10.7

Effective Number of Bits

ENOB

f

IN

= 15MHz, T

A

= +25

°C

60

10.3

Bits

Two-Tone Intermodulation
Distortion

IMD

TT

f

IN1

= 11.569MHz, f

IN2

= 13.445MHz

(Note 4)

-80

dBc
