Quad, 12-Bit, 65Msps, 1.8V ADC with
Serial LVDS Outputs
______________________________________________________________________________________ 13
ANALOG SUPPLY CURRENT
vs. SAMPLING RATE
f CLK (MHz)
I AVDD
(mA)
30 50 40 25 45 60 55 35
MAX1127 toc28
240
250
230
260
270
220
20 65
DIGITAL SUPPLY CURRENT
vs. SAMPLING RATE
f CLK (MHz)
I OVDD
(mA)
30 50 40 25 45 60 55 35
MAX1127 toc29
20
40
10
60
30
50
70
0
20 65
OFFSET ERROR
vs. TEMPERATURE
TEMPERATURE (°C)
OFFSET ERROR (%FS)
-15 10 60 35
0.03
0.04
0.02
0.05
0.06
0.01
-40 85
MAX1127 toc30
GAIN ERROR
vs. TEMPERATURE
TEMPERATURE (°C)
GAIN ERROR (%FS)
-15 10 60 35
0.2
0.6
-.0.2
-0.6
0
0.4
-0.4
-0.8
0.8
1.0
-1.0
-40 85
MAX1127 toc31
INTEGRAL NONLINEARITY
vs. DIGITAL OUTPUT CODE
MAX1127 toc32
DIGITAL OUTPUT CODE
INL (LSB)
1024 3072 2048 512 2560 3584 1536
-0.3
0
-0.4
0.4
-0.2
0.2
-0.1
0.3
0.1
0.5
-0.5
0 4096
DIFFERENTIAL NONLINEARITY
vs. DIGITAL OUTPUT CODE
MAX1127 toc33
DIGITAL OUTPUT CODE
DNL (LSB)
1024 3072 2048 512 2560 3584 1536
-0.3
0
-0.4
0.4
-0.2
0.2
-0.1
0.3
0.1
0.5
-0.5
0 4096
Typical Operating Characteristics (continued)
(AV DD = 1.8V, OV DD = 1.8V, CV DD = 1.8V, GND = 0, external V REFIO = 1.24V, INTREF = AV DD , differential input at -0.5dBFS,
f CLK = 65MHz (50% duty cycle), DT = low, C LOAD = 10pF, T A = +25°C, unless otherwise noted.)
