MAX1183
Dual 10-Bit, 40Msps, +3V, Low-Power ADC with
Internal Reference and Parallel Outputs
_______________________________________________________________________________________
3
ELECTRICAL CHARACTERISTICS (continued)
(V
DD
= +3V, OV
DD
= +2.5V, 0.1µF and 1.0µF capacitors from REFP, REFN, and COM to GND, REFOUT connected to REFIN through
a 10k
Ω resistor, V
IN
= 2Vp-p (differential with respect to COM), C
L
= 10pF at digital outputs (Note 5), f
CLK
= 40MHz, T
A
= T
MIN
to
T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Small-Signal Bandwidth
Input at -20dB FS, differential inputs
500
MHz
Full-Power Bandwidth
FPBW
Input at -0.5dB FS, differential inputs
400
MHz
Aperture Delay
t
AD
1
ns
Aperture Jitter
t
AJ
2
ps
RMS
Overdrive Recovery Time
For 1.5 x full-scale input
2
ns
Differential Gain
±1
%
Differential Phase
±0.25
Degrees
Output Noise
INA+ = INA- = INB+ = INB- = COM
0.2
LSB
RMS
INTERNAL REFERENCE
Reference Output Voltage
REFOUT
2.048
±3%
V
Reference Temperature
Coefficient
TC
REF
60
ppm/
°C
Load Regulation
1.25
mV/mA
BUFFERED EXTERNAL REFERENCE (V
REFIN
= +2.048V)
REFIN Input Voltage
V
REFIN
2.048
V
Positive Reference Output
Voltage
V
REFP
2.012
V
Negative Reference Output
Voltage
V
REFN
0.988
V
Differential Reference Output
Voltage Range
∆V
REF
∆V
REF
= V
REFP
- V
REFN
0.98
1.024
1.07
V
REFIN Resistance
R
REFIN
>50
M
Ω
Maximum REFP, COM
Source Current
I
SOURCE
5
mA
Maximum REFP, COM
Sink Current
I
SINK
-250
µA
Maximum REFN Source Current
I
SOURCE
250
µA
Maximum REFN Sink Current
I
SINK
-5
mA
UNBUFFERED EXTERNAL REFERENCE (V
REFIN
= AGND, reference voltage applied to REFP, REFN, and COM)
REFP, REFN Input Resistance
R
REFP
,
R
REFN
Measured between REFP and COM and
REFN and COM
4
k
Ω
Differential Reference Input
Voltage Range
∆V
REF
∆V
REF
= V
REFP
- V
REFN
1.024
±10%
V
COM Input Voltage Range
V
COM
V
DD
/2
±10%
V
REFP Input Voltage
V
REFP
V
COM
+
∆V
REF
/2
V
REFN Input Voltage
V
REFN
V
COM
-
∆V
REF
/2
V
