MAX1183
Dual 10-Bit, 40Msps, +3V, Low-Power ADC with
Internal Reference and Parallel Outputs
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DD
= +3V, OV
DD
= +2.5V, 0.1µF and 1.0µF capacitors from REFP, REFN, and COM to GND, REFOUT connected to REFIN through
a 10k
Ω resistor, V
IN
= 2Vp-p (differential with respect to COM), C
L
= 10pF at digital outputs (Note 5), f
CLK
= 40MHz, T
A
= T
MIN
to
T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
, OV
DD
to GND .............................................. -0.3V to +3.6V
OGND to GND.......................................................-0.3V to +0.3V
INA+, INA-, INB+, INB- to GND ...............................-0.3V to V
DD
REFIN, REFOUT, REFP, REFN,
COM, CLK to GND .................................-0.3V to (V
DD
+ 0.3V)
OE, PD, SLEEP, T/B
D9A–D0A, D9B–D0B to OGND ...........-0.3V to (OV
DD
+ 0.3V)
Continuous Power Dissipation (T
A
= +70°C)
48-Pin TQFP (derate 12.5mW/°C above +70°C)........1000mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-60°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
DC ACCURACY
Resolution
10
Bits
Integral Nonlinearity
INL
f
IN
= 7.51MHz
±0.5
±1.5
LSB
Differential Nonlinearity
DNL
f
IN
= 7.51MHz, no missing codes guaranteed
±0.25
±1.0
LSB
Offset Error
<±1
±1.7
% FS
Gain Error
0
±2
% FS
ANALOG INPUT
Differential Input Voltage Range
V
DIFF
Differential or single-ended inputs
±1.0
V
Common-Mode Input Voltage
Range
V
CM
V
DD
/2
±0.5
V
Input Resistance
R
IN
Switched capacitor load
50
k
Ω
Input Capacitance
C
IN
5
pF
CONVERSION RATE
Maximum Clock Frequency
f
CLK
40
MHz
Data Latency
5
Clock
Cycles
DYNAMIC CHARACTERISTICS (f
CLK
= 40MHz, 4096-point FFT)
f
INA or B
= 7.51MHz, T
A
= +25°C
57.3
59.6
Signal-to-Noise Ratio
SNR
f
INA or B
= 20MHz, T
A
= +25°C
56.8
59.6
dB
f
INA or B
= 7.51MHz, T
A
= +25°C
57
59.4
Signal-to-Noise and Distortion
SINAD
f
INA or B
= 20MHz, T
A
= +25°C
56.5
59
dB
f
INA or B
= 7.51MHz, T
A
= +25°C
65
76
Spurious-Free Dynamic Range
SFDR
f
INA or B
= 20MHz, T
A
= +25°C
65
73
dBc
f
INA or B
= 7.51MHz
-76
Third-Harmonic Distortion
HD3
f
INA or B
= 20MHz
-73
dB
Intermodulation Distortion
IMD
f
INA or B
= 11.6066MHz at -6.5dB FS,
f
INA or B
= 13.3839MHz at -6.5dB FS
(Note 2)
-78
dBc
f
INA or B
= 7.51MHz, T
A
= +25°C
-73
-64
Total Harmonic Distortion
(First 4 Harmonics)
THD
f
INA or B
= 20MHz, T
A
= +25°C
-73
-63
dBc
