MAX1566/MAX1567
Six-Channel, High-Efficiency, Digital
Camera Power Supplies
Designing a PC Board
Good PC board layout is important to achieve optimal
performance from the MAX1566/MAX1567. Poor design
can cause excessive conducted and/or radiated noise.
Conductors carrying discontinuous currents and any
high-current path should be made as short and wide as
possible. A separate low-noise ground plane contain-
ing the reference and signal grounds should connect to
the power-ground plane at only one point to minimize
the effects of power-ground currents. Typically, the
ground planes are best joined right at the IC.
Keep the voltage-feedback network very close to the
IC, preferably within 0.2in (5mm) of the FB_ pin. Nodes
with high dV/dt (switching nodes) should be kept as
small as possible and should be routed away from
high-impedance nodes such as FB_. Refer to the
MAX1566/MAX1567 EV kit data sheet for a full PC
board example.
Chip Information
TRANSISTOR COUNT: 9420
PROCESS: BiCMOS
