MAX1800

Digital Camera Step-Up
Power Supply

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(Circuit of Figure 1, V

OUT

= V

POUT

= 3.3V, PGND = GND, V

ONM

= 3.3V, V

ON1

= V

ON2

= V

ON3

= V

ONA

= 0, T

A

= -40°C to +85°C,

unless otherwise noted. Typical values are at T

A

= +25°C.) (Note 1)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

OUT, POUT, ON_, DCON_, FB_, RDYM to GND .....-0.3V to +6.0V
PGND to GND ......................................................-0.3V to +0.3V
OUT to POUT_ ......................................................-0.3V to +0.3V
LX, DL_, AO to PGND .............................-0.3V to (POUT + 0.3V)
REF, OSC, AI, COMP_ to GND..................-0.3V to (OUT + 0.3V)
Continuous Power Dissipation (T

A

= +70°C)

32-Pin TQFP (derate 11mW/°C above +70°C) ............880mW

Operating Temperature Range

MAX1800EHJ.................................................. -40°C to +85°C

Junction Temperature ......................................................+150°C
Storage Temperature Range. ............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

GENERAL

Input Voltage Range (Note 2)

V

IN

0.7

5.5

V

Minimum Startup Voltage

V

START

I

LOAD

< 1mA, T

A

= +25

o

C

0.9

1.1

V

Frequency in Startup Mode

V

OUT

= 1.5V

40

150

300

kHz

SUPPLY CURRENT

Shutdown Supply Current

V

ONM

= 0

0.002

5

µA

Main DC/DC Converter Supply

Current

V

FBM

= 1.2V, V

OSC

= 0

250

400

µA

Main + Auxiliary 1 Supply

Current

V

ON1

= 3.3V, V

FBM

= 1.2V, V

FB1

= 1.2V,

V

OSC

= 0

375

600

µA

Main + Auxiliary 2 Supply

Current

V

ON2

= 3.3V, V

FBM

= 1.2V, V

FB2

= 1.2V,

V

OSC

= 0

375

600

µA

Main + Auxiliary 3 Supply

Current

V

ON3

= 3.3V, V

FBM

= 1.2V, V

FB3

= 1.2V,

V

OSC

= 0

375

600

µA

Analog Gain Block Supply

Current

V

ONA

= 3.3V, V

FBM

= 1.2V, AI = REF,

AO open, V

OSC

= 0

375

600

µA

REFERENCE

Reference Output Voltage

V

REF

I

REF

= 20

µA

1.23

1.250

1.27

V

REF Load Regulation

10

µA < I

REF

< 200

µA

10

mV

REF Line Rejection

2.7V < V

OUT

< 5.5V

0.2

5

mV

OSCILLATOR

OSC Discharge Trip Level

Rising edge

1.225

1.250

1.275

V

OSC Input Bias Current

V

OSC

= 1.1V

0.01

100

nA

OSC Discharge Resistance

V

OSC

= 1.5V, I

OSC

= 3mA

37

75

OSC Discharge Pulse Width

100

ns
